FEATURES

1700W IP67 water-based fogger
60,000 CFM (cu ft/min) maximum output
Thermally protected heat exchanger
Intuitive DMX-512 and RDM control
Onboard LCD touchscreen
Optional wireless and wired remotes

SPECIFICATIONS

PERFORMANCE

Rated Power: 1700W
Max Output: 60,000 CFM* (cu ft/min.)
Ready Time: Initial = 14 Minutes*
Fluid Capacity: 1.32 gallons (5 liters)
Fluid Consumption: 6.76 oz/min (200 ml/min)
*approximate

COMPATIBLE FLUID

Atmosity Extreme Filtered Fog Fluid (AEF-2L, AEF-4L, AEF-20L)

CONSTRUCTION

Thermally Protected Heat Exchanger
Rugged Case Design
Convenient Carry Handles

CONTROL

3 DMX Channel Modes (1 / 2 / 4)
Onboard LCD Touch Control Panel
DMX-512 and RDM Protocol Support
Optional MAGFLY Wireless DMX Transceiver
Optional MAGRF Wireless and MAGREMOTE Wired Remotes

CONNECTIONS

Locking 5pin XLR Connector, DMX In/Out
IP67Locking Power Connector In
With Wired Digital Communication Network

SIZE / WEIGHT

Length: 648mm (25.5 in.)
Width: 332mm (14.6 in.)
Height: 411mm (16.2 in.)
Weight: 33,7kg (74.3 lbs)

ELECTRICAL

AC120V 60Hz (US Version)
AC230V 50Hz (EU Version)
20A @ 120VAC(NFB)
10A @ 230VAC - 240VAC
Max Power Consumption: 1700W

THERMAL

Maximum Ambient Temperature (Ta max): 40°C (104°F)
Exterior Surface Temperature, Steady State: 65°C (149°F)

OPTIONAL ACCESSORIES

MagFLY Card
MagRF Card

Specifications and documentation subject to change without notice.
