At Elation, we believe that great rELATIONships are the foundation of success. Whether it's through our innovative technology, personalized assistance, or exceptional customer service, we're committed to fostering strong rELATIONships that will drive your business forward.
We invite you to join us at the upcoming prolight+sound tradeshow in Frankfurt - Hall 12.1 B49, C49 - where you can meet our team and discover how Elation can help you achieve your goals through the power of positive rELATIONships. Build meaningful connections and discover how Elation can partner with you to realize success.
We're proud to offer the industry's broadest range of automated lighting complemented by professional Obsidian Lighting Control and dependable Magmatic Atmospheric Effects.
Visit Hall 12.1 B49, C49 at prolight+sound to learn all about our newest cutting-edge products.
Proteus Brutus™:
The Proteus Brutus is an exceptionally powerful 75000-lumen LED wash fixture with IP65 rating designed for piercing beam looks and high-intensity washes in any environment. A high efficiency 1200W 6500K white LED engine works with CMY color mixing, variable CTO and 6-position color wheel while a complete effects system features rotating gobos, animation, iris, and frost. An optional indexable framing module is also available. With a zoom range from 4° to 45° and an impressive 220mm (8.7") front lens, the Proteus Brutus cuts through at great distances.
Proteus Excalibur™:
The Proteus Excalibur is a stunningly powerful IP65 beam moving head set to assume the role as the new 21st Century searchlight. With extreme power (20000 lumens), super narrow 0.8° beam (3.5° Expander Lens available), and wide front aperture, it excels at creating aerial light beams, throws of CMY color, and air FX rivaling Xenon searchlights. It houses a wide array of gobos (25), prism overlays (4- and 8-facet) and more. The Excalibur uses Philips' highly-efficient Flex lamp technology for long lamp life, lower power consumption and reduced fixture maintenance.
Proteus Rayzor Blade™:
The Proteus Rayzor Blade is a combination of linear wash, high-intensity strobe line and SparkLED™ FX inside a compact IP65 linear fixture design. Available with 6 or 12 independently controlled 60W RGBW LEDs, Proteus Rayzor Blade provides well-defined mid-air beams up to 12500 lumens or exceptionally wide and even wash coverage. Two high-intensity strobe lines of cool white LED dots along with Elation's exclusive SparkLED™ effects add depth and visual impact. Wide zoom and dynamic tilt axis add to its visual flexibility.
Proteus Rayzor 1960™:
This compact yet extremely powerful LED wash effects luminaire with 5.6 to 44-degree zoom projects intense, well-defined mid-air beams, as well as an exceptionally wide and even wash coverage. Driven by 19 independently controlled 60W RGBW LEDs, the Proteus Rayzor 1960 provides a powerful beam (over 17000 lumens) that stands out on any stage. The oversized front lenses create a large surface enhanced by Elation's SparkLED™ technology for a unique additional layer of effect. Continuous, speed-adjustable pan & tilt rotation adds another layer of dynamic effect from this versatile fixture.
Fuze MAX Spot™ / Fuze MAX Profile™:
The Fuze MAX is a 21000-lumen full-spectrum LED moving head with RGBMA LED engine (92 CRI) that rivals 1000W/1200W class discharge fixtures. Available in Spot and Profile framing versions, the Fuze MAX has been designed for precision lighting applications such as theater, broadcast and Houses of Worship where a wider chromatic spectrum (including dynamic whites), a full feature set and outstanding quality is required.
Fuze Wash 500™:
The Fuze Wash 500 is a full-spectrum LED Fresnel moving head fixture designed for theater, television, events and a wide array of other precision lighting applications. It houses a 500W RGBMA LED engine and delivers a powerful output of up to 17,000 lumens with CRI of 92. It is designed for any application where an automated Fresnel fixture with outstanding and impactful colors, a wide zoom range and a soft field of light is required.
KL Profile FC™:
The KL Profile FC is a manual ellipsoidal framing fixture with 305W RGBMA LED engine designed for a wide array of precision lighting applications. With a 7 to 50-degree zoom, the fixture requires no additional lens tubes, reducing cost, complexity and providing excellent flexibility for any theater or performance venue. Included is a 16-bit rotating gobo slot and full blackout framing system with a Fresnel wash conversion kit available as an option. Output exceeds 10000 lumens.
KL CYC™:
The KL CYC is an ideal LED lighting solution for smooth and even cyclorama, set and wall washing applications. Housing an RGBMA color system, ensuring a seamless match with other fixtures in Elation's KL and Fuze lines, it utilizes a carefully crafted asymmetrical reflector design to achieve perfect blends while covering significant heights with ease. It is also an ideal choice for footlight positions, providing excellent versatility for stage, film, television and event lighting use. Seamless magnetic alignment, a simple mounting bracket attachment, and elegant power and data management make the KL CYC a breeze to integrate.
KL Panel XL™ / KL Panel XL IP™:
Designers have turned to Elation's color temperature-adjustable KL Panel full-color-spectrum LED soft light for livestreams and broadcasts of all types and now the company offers an XL version that extends the size of the original while emitting nearly twice the power and offering multi-zone control for dynamic effects. The new KL Panel XL soft light delivers superior output, precise color temperature control, full-spectrum color rendering and an even wash coverage. Optimized for the tunable white light requirements of broadcast, it is an ideal soft light source for many situations requiring outstanding performance and color quality. Also available is an IP65-rated model.
NX1™:
The NX1 from Obsidian Control Systems is a portable yet full-featured lighting console running Obsidian's powerful ONYX platform. Utilizing the full ONYX Operating System, the NX1 uses the latest in industrial components and offers a slate of professional features in an ultra-compact package. The console is expandable with the dedicated NX K keypad and the NX P motorized playback wing. A simple magnetic alignment system allows attachment on any side of the NX1.
Magma Fog 1500 IP™:
The Magma Fog 1500 IP from Magmatic effects is a durable, water-based fog machine with advanced technology and IP65 rating that provides an exceptionally high output fog for professional applications of all types. Hard to break but easy to use, a thermally protected 1500W heat exchanger produces an impressive output of 60,000 CFM (cu ft/min) and when operating at 100%, the unit can shoot a 40-second burst of all-enveloping dense fog.
