Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Fuze Profile
Code
1237000211
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/f/u/fuze-profile.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/g/r/green.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/p/u/purple.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/b/l/blue.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/s/n/snoot.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/f/t/ftop.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/f/s/fside.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/f/r/frear.jpg)
![](https://www.elationlighting.eu/pub/media/catalog/product/cache/9e8b08f8fc8d45187ddab759a10bb48c/f/u/fuzeprofile_bott.jpg)
FEATURES
Extended color RGBMA LED Engine, 92 CRIRotating and Fixed Gobos plus Animation Wheel
Full Blackout Framing System
Iris, Prism, and Frost
Wide Zoom Range from 7° to 42°
SOURCE
305W 6,500K RGBMA LED Engine30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.
PHOTOMETRIC DATA
10,100+ Total Lumen OutputCRI 92
Zoom Range 7° - 42°
Beam Angle 7.5° - 39.9°
Field Angle 8.6° - 44.2°
EFFECTS
Motorized Zoom4 Rotating Full Blackout Framing Blades, +/- 60 Index
Variable Frost Filter
4 Facet Prism
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
Pan Angle: 540°/630°
Tilt Angle: 270°
COLOR
RGBMA Color ArrayCMY Emulation
Variable CCT 2400K - 8500K
Green/Magenta Shift
Virtual Gel Swatch Book
GOBOS
1x 6 Rotating / Indexing Interchangeable Glass Gobos1x 7 Fixed Glass Gobos
Animation Wheel
CONTROL / CONNECTIONS
4 DMX Channel Modes (RGBMA 38 / 59) (CMY 36 / 55)16-bit Pan, Tilt, and Dimming Control
DMX Adjustable LED Frequency
DMX, RDM Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
16 Bit Resolution Adjustable Movement
5pin DMX In/Out
IP65 Locking Power Cable In/Out
With Wired Digital Communication Network
SIZE / WEIGHT
Length: 407mm (16.0”)Width: 256mm (10.1”)
Vertical Height: 698mm (27.4”)
Weight: 25kg (55.1 lbs.)
ELECTRICAL / THERMAL
AC 100-240V - 50/60Hz540W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 1841
FIRMWARE UPDATES
Current firmware can be found here (login required)
Specifications and documentation subject to change without notice
COLORS AND GOBOS
Gobo Wheel 1
![Gobo 17](/pub/media/gobos/wheel/Gobo17.png)
![Gobo 18](/pub/media/gobos/wheel/Gobo18.png)
![Gobo 19](/pub/media/gobos/wheel/Gobo19.png)
![Gobo 20](/pub/media/gobos/wheel/Gobo20.png)
![Gobo 21](/pub/media/gobos/wheel/Gobo21.png)
![Gobo 22](/pub/media/gobos/wheel/Gobo22.png)
Gobo Wheel 2
![Gobo 23](/pub/media/gobos/wheel/Gobo23.png)
![Gobo 24](/pub/media/gobos/wheel/Gobo24.png)
![Gobo 25](/pub/media/gobos/wheel/Gobo25.png)
![Gobo 26](/pub/media/gobos/wheel/Gobo26.png)
![Gobo 27](/pub/media/gobos/wheel/Gobo27.png)
![Gobo 28](/pub/media/gobos/wheel/Gobo28.png)
![Gobo 29](/pub/media/gobos/wheel/Gobo29.png)
Animation Wheel
![]() |
Prisms
![Prism 2](/pub/media/prisms/prism_2.png)
Framing
![]() |
