ELAR 108 PAR RGBW

ELAR 108 PAR RGBWArchive

Code 1236100053

More Power, More Punch, More Pixels... Designers and lighting professionals can dial up a spectrum of rich, perfectly blended colors for illuminating the largest stages, buildings, facades, landscapes and other entertainment or architectural elements where extreme output and/or direct view pixel blinder effects are desired with the Elar 108 Pars from Elation Professional.

Code 1236100053

ELAR 108 PAR RGBW

Technical Data

FEATURES

IP65 Rated

10° Beam 22° Field Angles

No-Service Convection Cooled

Flicker Free Operation for TV and FILM

Rugged Die-Cast Aluminum Exterior

Multiple Unit Power Linking

SOURCE

36x 3W RGBW LEDs

50,000 Hour Average Life

PHOTOMETRIC DATA

2,823 LUX @3M

EFFECTS

Electronic Strobe 1-25FPS

Color and Chase Macros

Electronic Dimming: 0% - 100%

CONTROL / CONNECTIONS

(4) DMX Channel Mode (4/5/7/9)

(4) Button Control Panel

Color LCD Menu Display

IP 3pin DMX In/Out

IP 3pin Power In/Out

SIZE / WEIGHT

Length: 232mm

Width: 185mm

Vertical Height: 218mm

Weight: 6,5kg

ELECTRICAL / THERMAL

AC 100-240V - 50/60Hz

120W Max Power Consumption

Multiple Unit Power Linking

-25°C to 45°C

Specifications and documentation subject to change without notice
