E Spot LED

• New 60W White LED Source
• 33000 Lux @ 1m With 6500°K
• 7 Rotating/Indexable/Interchangeable Gobos
• 8 Colors
• Prism / Focus
• Only 10,5kg / 43x20x30 cm

Technical Data

- New 60W white LED source (6500°K)

 - 50,000 hour rated LED source, 15° beam angle

 - 1 color wheel with total 8 colors + white

 - 1 gobo wheel with 7 gobos, interchangeable (quickout)

 - Gobo Size: 27mm outside, 22mm image diameter

 - Rotating, indexing prism: 3-facet 5-facet & 3D glass

 - Motor driven focus from near to far

 - Maximum Pan-movement 630° or 540°/ 16 bit

 - Maximum Tilt-movement 265° / 16 bit

 - 3 Phase motors for fast, accurate Pan / Tilt positioning

 - 3-digit LED Display

 - 14 DMX channels USITT DMX-512 (16-bit resolution)

 - Other DMX modes available

 - DMX, stand-alone, Primary/Secondary, sound activated mode

 - Fan cooled - fans regulated by automatic

 - 1 x 1/4 turn fastening Omega Clamps

 - Power consumption: 167W

 - Voltage: AC 100V ~ 240V 50/60Hz

 - Dimensions (LxWxH): 435x204x301mm (Head up)

 - Weight: 10,5 kg

Specifications and documentation subject to change without notice
